QP Series Fire Alarm Control Panel

  Characteristics

• Removable front board for easy maintenance.
• Easy-to-clean front board is able to avoid dirt attached.
• High luminance and long life span LED.
• Build-in 24V power and battery charger.
• Independent visual & audible indication for zone open/short fault.
• Independent visual & audible indication for AC power & battery fault.
• Visual & audible indication for sounder short circuit fault.
• Buzzer silence with 3-mode operation feature.
• Short circuit = Alarm feature (selected by JUMPER, applicable for manual call point w/o resistance).
• Accurate supervision circuit for battery.
• Day/Night Mode Selection. (Model. QP212, QP412)
• System will back to normal automatically after alarm status is released. (Model. QP212, QP412)
• Ground fault detection feature. (Model. QP212, QP412)
• Fault Output (NO. NC. COM), Alarm Output (NO. NC. COM.), Zone Output. (Model. QP212, QP412)
• 24V DC power output for external load. (Model. QP412)
• Zone EOL resistor can be set from panel board. (Model. QP412)

Approval
