Description
| Protek | Fire Monitor | |||||||
| Style | 636 | |||||||
| Max. GPM (LPM) | 750 ( 2900 LPM ) | |||||||
| Inlet Size | 3″ ( Flange ) | |||||||
| 4″ ( Flange ) | ||||||||
| 6″ ( Flange ) | ||||||||
| 2-1/2″ ( Female Thread ) | ||||||||
| Outlet | 2-1/2″ | |||||||
| Control | Tiller Bar | |||||||
| Material | Brass | |||||||
| Finish | Red Powder Coating | |||||||
| Friction loss | 35 psi at 750 GPM 18 psi at 500 GPM |
|||||||
| Travel | 135° vertical 360° Rotation |
|||||||
| Weight | 44 Lbs. ( 20 Kg ) | |||||||
| Certification | FM Approved | |||||||
Unique Features of protek Industrial Monitors Style 636
- Powder coating produces a tough, corrosion resistant finish
- Positive friction locks for both horizontal and vertical travel to hold desired position
- Stainless steel lever for durability and easy control
- Major components made from brass alloy ( UNS C83600, ASTM B62 ) for a long-lasting service life
- Optional flanges : ANSI, ASA, DIN or ISO
- Double-row stainless steel ball bearings in monitor joints ensure smooth movements even when the monitor is under pressure
- Compatible with Protek’s diverse range of water and self-educting foam monitor nozzles for various applications
- Optimises advanced computer aided design and testing technology to minimise flow turbulence
 |
|
|
|
|
|
|
|
|
|
|
